This example is for Wiring version 1.0 build 0100+. If you have a previous version, use the examples included with your software. If you see any errors or have comments, please let us know.
Pitch follower by Tom Igoe
Plays a pitch that changes based on a changing analog input circuit: 8-ohm speaker on digital pin 8 photoresistor on analog 0 to 5V 4.7K resistor on analog 0 to ground
Plays a pitch that changes based on a changing analog input circuit: 8-ohm speaker on digital pin 8 photoresistor on analog 0 to 5V 4.7K resistor on analog 0 to ground
void setup() { // initialize serial communications (for debugging only): Serial.begin(9600); } void loop() { // read the sensor: int sensorReading = analogRead(A0); // print the sensor reading so you know its range Serial.println(sensorReading); // map the pitch to the range of the analog input. // change the minimum and maximum input numbers below // depending on the range your sensor's giving: int thisPitch = map(sensorReading, 400, 1000, 100, 1000); // play the pitch: tone(8, thisPitch, 10); }
